How to Set Up an L298N Motor Driver Module in Proteus | DC Motor Control Tutorial

This video demonstrates how to set up an L298N motor driver module in Proteus Software. The circuit allows you to control the direction and speed of a DC motor using simple digital inputs. Key Features: Dual H-Bridge Design: Drives two motors simultaneously. 12V Power Supply: Provides power to the motor. 5V Logic Supply: Powers the control inputs. Direction Control: Use ENA, IN1, IN2 pins to toggle motor direction. Speed Control: Add a PWM signal to ENA/ENB pins (not shown here) for variable speed. How It Works: Power Connections: Connect +12V to the motor terminals (OUT1-OUT4). Connect +5V to the logic inputs (ENA, IN1, IN2). Direction Control: For forward motion: Set IN1=HIGH and IN2=LOW. For reverse motion: Set IN1=LOW and IN2=HIGH. Enable Pin (ENA): HIGH enables the motor; LOW disables it. ⚠️ Safety Note: Always use heat sinks on L298N for high-current applications. 🔔 Subscribe for more tutorials, and hit the bell for updates! Telegram channel link: https://t.me/electronic_simulation Subscription Link:    / @electronicsimulation9618   🌐 Check out my other channels:    / @makercreative      / @openpcb      / @electronicsimulation9618   #L298NMotorDriver #DCMotorControl #ProteusSimulation #ElectronicsTutorial #HBridge #ElectronicProjects #EngineeringStudents #ElectricalEngineering #STEMEducation #BeginnerProject #StudentProject #ScienceProject #HowToBuildACircuit #LearnElectronics #RealTimeSimulation #CircuitAnalysis #PowerElectronics
