ATACAMA leveller - Italiana Ferramenta

ATACAMA is the new leveller to align heavy duty wardrobes, bookcases and modular furniture. Suitable for 60mm plinths. It is fixed on the furniture bottom through two housings, in order to provide an easier and more stable installation. A lateral pin slots into the furniture side to achieve a structural connection, as well as an equal load distribution over the furniture side and base. Finally, two screws secure Atacama to the furniture bottom. A Ø8mm through hole in the furniture bottom allows to adjust the leveller from above, by using a S6mm allen wrench or a 1X5.5mm blade screwdriver. Capable of supporting a 175kg load each. 25mm adjustment. Tested according to Italian CATAS Institute requirements.
