Roland FA-06 fix tactile switch

One of the many press switches on my synth stopped working. This video shows how to take the synth apart, and replace the faulty switch attached to a circuit board. I'm in the UK. The part I used came from https://cpc.farnell.com/ and is part number MC32881. There is also an equivalent from https://www2.mouser.com/ - part number 612-TL59AF160Q. Their warehouse in the the USA. The key element is the height of the switch (5mm) and the space between the 2 legs (5mm) I was helped by watching video at    • Roland Fa 06 | Replacing tact Switch Butto...  , which involves a lot more switches and also replacing some of the potentiometers. If you want a bit more detail on taking the bottom off the synth, please watch my video at    • Roland FA-06 teardown / dismantle for repair   0:00 Problem outline 0:41 Removing bottom 1:04 Internal layout and circuit boards to be removed 2:23 Removing boards 5:42 Replacing the switch on the circuit board 7:43 Reassembly 10:37 Test
