How Does Rake Classifier Work | Indofab

Working of Rake Classifier The rake classifier consists of a rectangular tank with a sloping/inclined bottom. The tank is provided with movable rakes (reciprocating rakes). The feed in the form of a suspension (slurry) is introduced continuously near the middle of the tank. The lower end of the tank has a weir overflow (discharge weir) from which the fines that are not settled leave with the overflow liquid. The heavy material (coarser particles) sink to the bottom of the tank. The rakes scrap the settled solids upward along the bottom of the tank toward the top of the tank for discharge from a sand-discharge chute. The reciprocating rakes keep the slurry in continuous agitation. The time of raking stroke is so adjusted that fines do not have time to settle and so remain near the surface of the slurry, while the heavy particles have time to settle Process Timestamp : 0.56 Link to download FREE OUTLINE DRAWING https://indofab.com/e-store.html For more info. Please visit our Official Website https://www.indofab.com We are also on Facebook fb.me/indofabindia m.me/indofabindia and Twitter   / indofabindia
