MAKO 5G Dome Antenna

The MAKO 5G Dome range has been designed to provide 4x4 4G/5G MiMo performance from 617-960/1710-6000MHz in a robust low profile package. The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and up to 6x6 MiMo WiFi 2.4/5.0GHz. The antenna is designed to be panel mounted and can be fitted on a conductive or non- conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UNECER 118 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications. The LGM variants have an integrated GPS/GNSS module supporting GPS, Glonass, Galileo, QZSS, and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in-band interference. The antenna is available with a black or white radome which meets IK10 for vandal resistance and IP69K for Ingress protection. Key Features: Low profile 4x4 MiMo 4G/5G LTE Up to 6x6 MiMo WiFi 2.4/5.0GHz 617-960 / 1710-6000MHz Optional GPS/GNSS with advanced B13/14 filtering Flame retardant materials: UNECER 118 and EN45545-2 compliant cables & flame retardant Halogen-free radome Certified to IP69K for ingress protection and IK10 for impact resistance Environmentally compliant: Meets RoHS, REACH, PVC free Application: Police Ambulance Fire and Rescue Services Public Bus Transportation Utility Contact Panorama Antennas and find out more. http://bit.ly/2zYDK0G ------------------------------------------------------------------------------------------------------------------------- Product Details: https://bit.ly/36FjxzT Follow us on LinkedIn: https://www.linkedin.com/company/pano... 0:00 Panorama Antennas 0:06 MAKO 5G Dome Antenna 0:14 Features 0:24 Benefits 0:36 Cable Tails 0:44 Application 0:53 Product Variants 1:05 Outro
