Intel SRR3 Project Lifting of Composite Deck Floor Slabs of High Rise Commercial Building Fagioli India's recently completed one of the most challenging civil works ever done, the lifting and locking of 10 Floor composite Slab sections complete with mechanical, electrical, interiors and facade works of 3 wings using multiple combination of Fagioli Strand Jacking System. The project was first of its kind for Fagioli India, where complex synchronized lifting arrangement with different capacity of jacks was involved. Facts • Fagioli expertise in handling strand jacking had once again proved that such a unique slab erection works can be done without any error, safeguarding all the norms, structural works and safety. • Fagioli was able to concluded all the floor slab lifts two months ahead of scheduled time, a remarkable achievement in construction industry. Fagioli Lifting Equipment • 30 units 100 ton and 28 units 180 ton of Fagioli's Strand Jacks Items Lifted • 10 units Knuckle Slab 360 ton, Single Slab 27.7 m x 27.7 m • 20 units A wing and B wing Slab 1350 ton, Single Slab 45.5 m x 27.7 m Advantage of Fagioli Lifting System in use • Safety: working at or closer to ground level; reduced chance of falls and potential injury; reduced crane requirement. • Quicker: direct worker, equipment and materials does not need to work from higher ground; the technique also allows several areas of construction to run concurrently; In this job all the MEP, Facade and interiors were in place on ground before it lift; allowing multiple subcontractors to work together and complete the work earlier • Improved Quality: all load bearing steel were Shop Fabricated which gives greater possibilities of improved quality; and improved safety avoiding Site Fabrication works; likewise inspection will be more thorough and advanced • Time Factor: working at ground level increases productivity; reducing schedule time frame; multiple group works at once at same; strand jacking system allows parallel working conditions without any hold; crane handling work dependency is reduced
