Equipment in this video is made by Jesper G. i guess about 1976, the XR2206 in this video is the old original with the spike error, they fixed this in later versions, the IC was made from 1970 to 2004 by EXAR Corporation, even today you can find cheap kits with this function generator all in one IC. this unit actually works, is full of trimers for adjusting all things perfectly in, Sweep input, and AM modulation input too. it can even do both modulations at the same time. this MK case measurements in mm Deep 215, Width 156, Height 108 #diyelectronics #test #teardown -- I use auto generated subs, so if you find errors worth fixing, please comment with the time in the video you saw the error, i will be happy to fix it. This also apply to the Danish version. -- (Thanks to all my Sponsors / Traders / Swappers / Sellers / Buyers, without your support and constant flow of cool items in/out, none of this would be possible)
