A BRIGHT AND BEAUTIFUL 5-AXIS MODULAR WORK-HOLDING FIXTURE | ELIJAH TOOLING

A BRIGHT AND BEAUTIFUL 5-AXIS MODULAR WORK-HOLDING FIXTURE www.elijahtooling.com Hey guys, Rick here from Elijah Tooling. I've got this fixture here that we are going to be sending out to a customer. I thought I would take a few minutes and show you a few things about it. As you can see, I can literally move it around because it is in this box. Round Modular Fixture This is a round cnc-workholding modular-fixture that is going into an Okuma Trunnion Type 5-Axis machine. And, as you can see, we have set it up with a standard two-inch pattern, just like we have talked about before. It has got the new Invert-A-Bolt Fasteners in it and it has also got the multi-purpose holes. We have talked about them before but, as you can see, it is a bored and threaded hole. Flex Vise on a round modular fixture In this case, we are shipping one of our dove-tail vises, the FlexVise with it. But, what I thought was cool and what you should see, is that we have made it so it would adapt to the T-slot fixture that it's going into. Center Plug in round modular fixture This particular machine has a center plug and we have created a screw-in, precise locating plug that then will locate with respect to a location in the slot. Locator on a round modular fixture Here is the other locator. So we have got a locator, another locator, and in between them is the center slot. You can see that we are using our 18-millimeter T-slot Fastener to hold the plate. T slot fastener on round modular fixture This is "kind of" set up the way it is going to look on the machine once it is in the fixture. The T-slot Fastener can come out quite easily and it is in line with the slots and makes for a perfect scenario, in which you have got this fastener that is sitting in this slot and is not moving around. This plate is made specifically for this. You have also got all these locations. You can see that the threaded holes go all the way through; you do not have to really worry about how deep that screw is going in. That's about it. We have talked about modular fixture plates before, but I thought this was a beauty, and that we ought to show it to you before it is out the door. Notice this nice heavy box? That is how they are shipped. It also comes with an inspection port so that you know that this is precisely made and will do the job that you want it to do. Thank you for your time! -Rick Like what you see here? Follow us on LinkedIn for more content from Elijah Tooling. Rick Miller's LinkedIn:   / rick-miller-957a2b16   Elijah Tooling's LinkedIn:   / elijahtooling   We care about CNC machining, CNC machinists, CNC tools, CNC tooling, and precision machining! Our passion is efficiency, speed, modular workholding and the people that make machining great! #cnc #aerospace #industrial #machining www.elijahtooling.com
