VW & SKODA CLIMATRONIC Self-Diagnostics - How to diagnose a problem with climatronic system

How to diagnose a problem with climatronic system 1.)Press and hold the ECON and Recirculate buttons simultaneuously for about 2 seconds and turn ignition ON 2.)Turn Ignition ON 3.)To scroll the next error code press the warmer button. If no codes 444 is displayed 4.)When all codes have been displayed 000 is displayed 5.)To clear the error codes press and hold ECON for at least 2 seconds 444 will been displayed as confirmation that there are no more codes present 6.)To exit the internal error memory mode briefly press ECON button List of Possible Error Codes: (Error Code / Error Location / Error Type) FFFF Control Unit 0x25 0119 Vehicle Speed Sensor 0x25 0214 Supply Voltage 0x06, 0x07 021A Reference Votlage 0x06, 0x07 0510 Temperature Sensor – Dash Vent (1296) 0x1d, 0x1e 0511 Temperature Sensor – Footwell Vent (1297) 0x1d, 0x1e 030B Outside Temperature Sensor – Front Bumper 0x1d, 0x1e 0313 Temperature Sensor – Fresh Air Inlet 0x1d, 0x1e 0332 Temperature Sensor – Evaporator 0x1d, 0x1e 0333 Refrigerant Pressure Sensor 0318 Air Conditioner Pressure Switch 0x23 031D Photosensor for Sunlight Intensity 0x1d, 0x1e 0382 Compressor Valve 04F7 Temperature Flap Servo Motor 0x25 04F8 Central Flap Servo Motor 0x25 04F9 Fresh Air Blower 0x25 04FA Recirculation Flap Servo Motor 0x25 025B Footwell/Defrost Flap Servo Motor 0x25 04B6 Standing Time Signal 0x25 0538 CAN-Bus 0513 Gateway 053D Kombi 04AE Gateway Database Version 0414 Control Unit Not Coded 0x23 043F Basic Settings Not Accomplished 0x23
