PLC program (EasyVeep) - Lock chamber control

Ships arrive at the lock from both directions. The aim is to control the lock chamber so that the ships can pass the section of river with no accidents. The ships automatically enter the lock chamber when the entry signal shows green. They sail out when the exit gate is fully open. For test purposes, you can stop ships approaching or have the ships continue to sail if you click with the mouse on the corresponding red lamp (bottom) or green lamp. I0.0 Gate on the left closed I0.1 Gate on the right closed I0.2 Water level low I0.3 Water level high I0.4 Ship from left I0.5 Ship at the left gate I0.6 Ship in the lock-gate I0.7 Gate on the left is open I1.0 Gate on the right is open I1.1 Ship at the right gate I1.2 Ship from right O0.0 Open the gate on left side O0.1 Open the gate on right side O0.2 Increase the water level O0.3 Decrease the water level O0.4 Free sign on left side O0.5 Free sign on right side Info:aladar.lakatos@gmail.com
