Super powerful amplifier homemade from scrap

We are going to assemble a super powerful homemade amplifier using most of the components found in scrap metal. Using transistors 2sa1943 and 2sc5200, as pre-amplifier the ci4558. This amplifier promises to deliver a power of 150W. I hope it helps! We will show you a very simple step by step! List of components - 2.SC5200 2.SA1943 4. Resistor 033 ohms 5w 4. 100 ohm 1w resistor 2. 15K resistor 2. 220 ohm resistor 1. 1K resistor 1. 100K resistor 2. 33K resistor 2. 3.3K resistor 2. 1.5K resistor 1. 18K resistor 1. 10 ohm 5W resistor 2. Diodes 1N 4007 2. 15V zener diodes 1. Type 41 Transistor 1. Type 42 Transistor 1. CI 4558 1. 0.1uf polyester capacitor 2. Electrolytic capacitor 470uf X 25V 2. Electrolytic capacitor 47uf X 50V 2. Electrolytic capacitor 1uf X 16V 1. 10K potentiometer List of components for font 01. Transformer 35+35 01. Rectifier bridge 100V 5A 02. Electrolytic capacitor 8000uf X 63V Welcome to the Mais Projetos Channel! Let's learn how to assemble various electronic circuits in a simple way, straight to the point. I will show you how to assemble a sound amplifier with transistors found in scrap metal, using 13007, 5200, 1943 and several other transistors. Power inverters, vu meter, vu led, energy detector are some of the projects I intend to bring, leave your suggestion for the channel videos!
