Proxxon BFW 40/E Spindle Power Supply Teardown (Circuit, Waveforms)

I take a peek inside and break out the oscilloscope for a closer look… ↓↓↓ Complete description, time index and links below ↓↓↓ Some weeks ago I did overhaul my Proxxon BFW 40/E spindle motor (link below). But I couldn’t open up the power supply, because of some darn security screw. Meanwhile my Chinese friends came through and sent be the appropriate bit. So I took it apart to find, well, more dirt (which I cleaned of course) and a very simple but surprisingly effective SCR circuit for regulating the spindle speed. Of course I reverse engineered it and had a look at the waveforms on the scope. 00:00 Intro – a little help from my Chinese friends 00:33 Insides – transformer and eleven electronics parts 04:40 Circuit – SCR based regulation with a dozen parts 07:43 Waveforms – shown on the oscilloscope 14:15 Reassembly – as easy as taking it apart 17:49 Wrap-up – that’s it, bye Teardowns    • Teardowns   Proxxon BFW 40/E Spindle Overhaul (Cleaned, Brushes Checked, Collet Polished)    • Proxxon BFW 40/E Spindle Overhaul (Cleaned...   #proxxon #teardown #disassembly #disassembling #circuitdiagram #schematics #robertssmorgasbord
