Spigot And Socket Joint, Key and Cotter Joint, With the help of Mini Drafter,

PDF LINK https://drive.google.com/file/d/1UYUP... SOCKET AND SPIGOT COTTER JOINT A cotter joint knows as a socket and spigot joint, is a method of temporarily joining two coaxial rods, one end of the rod provided with a socket type and the other end of the other rod inserted into the socket. The end of the rod goes into a socket also called a spigot. A rectangular hole is built into the socket and spigot. A cotter is tightly operating through a hole to make a temporary connection between the two rods. The load is usually acting axially, but it changes its direction. And so, the cotter joint should design to carry both tensile and compressive loads. Compressive load taking by the caller on the spigot. PLEASE LIKE AND SUBSCRIBE #Saifim 03
