Radar Alignment Walkthrough: 2023 Toyota RAV4 | ADAS Calibration Training

🚀 Looking to perform faster and more accurate ADAS calibrations? Start with *7StepBox™ — now 20% Off!* Buy it here 👉 https://www.7stepadas.com/7stepbox-yo... (Discount automatically applied. Limited promo batch — only 20 units available.) ⚙️ Precision-built. No alignment rack required. Ships in 96 hours. 🛠️ 7 Step ADAS Recommended Tools: https://www.7stepadas.com/tools/?utm_... In this video, we show how to perform a static radar verification on a 2023 Toyota RAV4 using the 7 Step ADAS method — all without a right-side reference line. This test challenges Toyota’s OEM bumper height spec (850mm), comparing real-world outcomes at 860mm and 800mm, and shows what happens when spec alignment doesn’t match field results. It's a full walkthrough of how to problem-solve sensor placement issues before calibration fails. Timestamps 00:00 – Intro & Overview of the Setup 01:15 – 3 OEM Methods: Triangle, Flat Target, Driving Adjustment 02:45 – Why We’re Skipping the Right Side Line 04:20 – Front Line Setup Using Left Laser + Bosch Square 06:00 – Establishing the Center Line with Plumb Bob 07:30 – Target Placement at 850mm, Then Testing Other Heights 09:40 – Horizontal Misalignment Despite Centering 11:00 – Reattempt at 860mm & Off-Road Spec at 800mm 13:10 – Results Comparison: No Adjustment Possible 14:30 – What This Means for Technicians in the Field 15:20 – Closing Thoughts & What Worked Best Highlights 📏 Target Height Matters: Verifying against 850mm, 860mm, and 800mm 🔧 Real-World vs Spec: OEM says it should work — but it doesn’t always 🧠 Line Geometry Done Right: Alignment achieved without a right side line 🚫 No Adjustments Available: Sensor is fixed-mount — no tuning screws Key Insights You can confidently align without a right side line using the 7 Step ADAS method. OE spec height (850mm) sometimes fails — off-road spec (800mm) might perform better. Not all radars allow physical adjustments — verifying placement first is essential. Static calibration prep is just as important as the actual calibration process. Closing Statement If you have any questions, feel free to reach out to us in the comments. Thank you for watching! #RadarAlignment #ToyotaRAV4 #ADASCalibration #7StepADAS #ToyotaRadar #SensorAlignment #ADASRepair #StaticCalibration #CollisionRepair #RadarSetup Our Links: 🔹 Our Shop Management: www.completeautoreports.com @CompleteAutoReports 🔹 Our ADAS Advice, Tips, & Tricks: www.7stepadas.com 𝐃𝐢𝐬𝐜𝐥𝐚𝐢𝐦𝐞𝐫: The information presented in this video is for general informational and educational purposes only. No guarantee is made regarding the accuracy, completeness, or safety of the procedures, tools, or techniques shown. Vehicle repair, diagnostics, and calibration involve inherent risks. Always follow manufacturer instructions, use appropriate safety equipment, and consult qualified professionals when necessary. The creators of this content assume no liability for injury, damage, or loss that may result from the use or misuse of any information, tools, or equipment demonstrated or referenced. By watching this video, you acknowledge that you are solely responsible for how you apply the information contained herein.
