CLOUDRAY-CAD：Change to F160 Lens for Precise 2D Laser Engraving

IMPORTANT: Section 1: Z-Axis Safety 1. Z-Axis Connection Warning: If you need to manually adjust the column height or move the Z-axis, please power off the machine and then disconnecting the Z-axis cable. Pro-Tip: Never hot-plug the motor cables as it may damage the stepper driver. Section 2: F160 Lens Calibration 2. F160 Field Lens Focus Adjustment: The nominal focal length for the F160 lens is 192mm. However, due to manufacturing tolerances, the actual focus may vary slightly. How to find the perfect focus: Manually move the Z-axis up and down while marking until you see the brightest spark/strongest light intensity. This is your true focal point. Section 3: Optimized Engraving Settings 3. Recommended Dot Pitch for Images: For the best 2D engraving results, we recommend a Dot Pitch of 0.04. Adjustment Range: 0.02 to 0.05. Section 4:Power vs. Pulse Width Logic Power cannot be adjusted directly on this system; it is controlled via Pulse Width. Inverse Relationship: The Pulse Width is inversely proportional to the peak power output. Adjustment Range: 1 - 30 (ns).
