Solar Pump Installation | HYBSUN Solar Well Pump Kit

Solar Pump Installation Guide | HYBSUN Solar Well Pump Kit This video provides a step-by-step guide to install and wire your HYBSUN Solar Well Pump Kit. Perfect for off-grid solar water pumping systems, this tutorial covers pump wiring, installation, controller setup, and solar panel and battery connections. Video Chapters: 00:00 Solar Pump Wiring 04:47 Solar Pump Installation 06:12 Solar Controller Installation 09:04 Solar Panel and Battery Connection Topics Covered: Solar Pump Wiring: Strip cables, connect terminals, and waterproof the connections. Pump Installation: Securely place the pump into the well using a rope and SS304 clamps. Solar Controller Installation: Mount the controller using SS304 screws and ensure stable placement. Controller Wiring: Properly connect pump, well float, and tank float cables to the controller. Solar Panel and Battery Connection: Safely connect solar panels and batteries to the controller without damaging polarity. Key Steps for Each Section: 💡 Solar Pump Wiring Strip 1cm of the pump and extension cables. Use heat shrink tubes, cold-pressed terminals, and waterproof tape to secure and insulate the connection. Optionally, use a resin straight-through cable gland for extra durability. 💡 Pump Installation Attach a PVC outlet connector and secure it with an O-ring and thread-sealing tape. Fix the water pipe with an SS304 hose clamp and lower the pump into the well using a nylon rope. 💡 Controller Installation and Wiring Mount the controller securely with SS304 screws. Connect pump cables (brown, blue, black) to the UVW terminals and float wires to their respective terminals (TH, COM, WELL). 💡 Solar Panel and Battery Connection Connect solar panel and battery terminals to P+ and P- of the controller. Ensure correct polarity to avoid damage. Why Choose HYBSUN Solar Pumps? High-efficiency off-grid pumping solutions for wells and water tanks. Durable design with easy-to-follow setup. Eco-friendly and cost-effective water management. 💡 First-time customers get 30% off! 🎉 📍 Visit: https://www.hybsun.com/ 📧 Email: Tiger@hybsun.com 📞 WhatsApp: +86 187 0586 1702 If this video helped you, Like, Comment, and Subscribe for more solar pump tutorials! Have questions? Drop them in the comments below!
