Kitamura HX400G Steel Cutting Demo

Filmed on July 24, 2014 at Machinery Sales Co. City of Industry, California. Test cut prepared and operated by Dave Fittery Applications Engineer. Kitamura HX400-G Steel Demo Test Cut Material: 1045 C.F. Steel 3” x 6” x 2.0” Workholding: Chick Tower with Double Vises Jaw Depth ½” 1.) 2.0” Shell Mill (90 degree) 5 Inserts / 525 SFM / 1000 RPM / 35 IPM / 0.007” per Tooth 0.260” Depth of Cut x 1.50” Width of Cut (130 %) 2.) 1.50” End Mill (90 degree) 3 Inserts / 785 SFM / 2000 RPM / 50 IPM / 0.0083” per Tooth 0.325” Depth of Cut……Full Width Slot (110%) 3.) 0.625” Solid Carbide End Mill with AiTlN coating 4 Flute / 820 SFM / 5000 RPM / 135 IPM / 0.0068” per Tooth 0.800” Depth of Cut with 0.030” Step Forward Trochoidal Milling (15%)
