SLLIMM HP: high power intelligent modules for industrial motor drives

Find out more information: https://bit.ly/sllimm-hp SLLIMM high power (HP) is a series of compact, powerful, dual-in-line intelligent power modules (IPMs) from the STPOWER family. It expands the existing SLLIMM family taking performance to the next level in terms of breakdown voltage, current capability, power range and density. Designed using an innovative configuration of the internal drivers and a high level of integration, the SLLIMM HP series features three high-side drivers, one low-side driver, trench gate field-stop IGBTs and free-wheeling diodes, including NTC and bootstrap diodes as well. The SLLIMM HP series can bring to your design increased thermal dissipation capabilities thanks to the DBC HPS substrate, an extended power range for applications, as well as system integration and compactness reducing the BOM. The SLLIMM HP series is tailored for industrial applications such as HVAC (heating, ventilation, air conditioning), servo motors, general-purpose inverters and industrial washing machines, operating up to 7 kW. SLLIMM stands for: Small Low-Loss Intelligent Molded Module.
