ZOPO SP2580FII Double Column Machining Centre Dugard Available at Dugard скачать в хорошем качестве

ZOPO SP2580FII Double Column Machining Centre Dugard Available at Dugard

http://www.dugard.com for more information ZOPO SP2580FII Double Column Machining Centre SP2560 Classic T type ram series The first choice for processing small molds, mechanical parts, petroleum, aviation, rail transportation and other industries 6200/2900/1000mm TRAVEL 2500x6000mm WORKTABLE 6000rpm SPINDLE SPEED 10/10/10m/min RAPID FEED RATE Serialized and modular design ZOPO classic T type ram series double column machining center adopts advanced design concept, combined with Finite Element Analysis(FEA), which can effectively reduce the deformation of the machine during machining, and improve the machining accuracy and accuracy retention at the same time. Modular design provides customers with more configuration options. The products are rich in variety and complete series to meet the processing needs of different industries; suitable for aluminum alloy, cast iron, steel and other materials. The overall appearance design easy the operation and maintenance after comprehensive study of ergonomics , especially optimized design of waterproof and chip removal system. High precision and high stability structural design All castings are made of high-strength gray cast iron with vibration absorption ability, and are aged to ensure stability. The reinforcing ribs are well designed to have excellent bending resistance to ensure the stability of the machine tool. Ram：Optimal central symmetrical spindle box design; hard rail with extra-large cross-section and high rigidity; overall rigidity increased by 20%. Worktable：The worktable is hollowed out, and the moving parts are lightweight, which improves the response speed of the worktable. Machine body：One-piece casting bed and internal reinforcement rib design ensure stability and high rigidity; simplify assembly process, reduce assembly errors caused by personnel, and improve machine tool stability. Beam：The optimal stepped beam and saddle design shifts the overall center of gravity of the spindle box backwards, increasing the machining rigidity. Parameters Working range Unit X/Y/Z axis travel 6200/2900/1000mm Distance between two columns 3000mm Distance from table surface to spindle nose 220-1220mm Worktable Unit Worktable size 2500x6000mm T-slot size 11-28*200mm Max. load bearing of worktable 25000kg Spindle Unit Spindle hole taper BT50 Main motor power 22/26(Wide area)KW Spindle speed 6000(Gear head)rpm Feed Unit Max. feed speed 8000mm/min Rapid feed rate 10/10/10m/min Machine Unit Machine dimension 15000*6800*5700mm Machine weight 50000kg Easier to use and more powerful control system Relying on the in-depth collaboration between ZOPO engineers and CNC system companies, we continuously carry out secondary development based on standard CNC systems to create multifunctional and intelligent human-machine interfaces, creating a more efficient and convenient user experience for customers. Selection of energy-efficient processing modes Tool management function Broken tool detection function Troubleshooting guide function Super powerful human-computer interaction interface
