When assembling structures made from Rexroth structural aluminum framing (MGE), the Central Bolt (AKA Connection Screw) is absolutely the simplest connection for fixed-point right angles! This video uses 45-series Rexroth profile, but will work with any Rexroth profile that has a 10mm T-slot. 9.8mm clearance hole should be drilled 18.5mm from the cut edge of the profile, centered in the T-slot. (Drilling jig also available, see link below) This demonstration assumes an end cap will be added to the assembly, and uses the following items: Connection Screw, M12x30: https://shop.flexmation.com/products/... Connection Screw, S12x30 (self-tapping): https://shop.flexmation.com/products/... - This style of screw can be used with an impact wrench in cases where a tapping bit is not available. Assembly instructions are the same, but pre-tapping of the profile is not necessary. 45-Series Aluminum Profile: https://shop.flexmation.com/products/... End cap: https://shop.flexmation.com/products/... Drilling jig also available: https://shop.flexmation.com/products/... Watch for more instructional videos coming soon!
