2009 Buell 1125CR Oil Change

2008 2009 Buell 1125CR and 1125R. Should be the same for the later EBR motorcycles with the Rotax Helicon engine. Ride the motorcycle to verify the engine is at normal operating temperature. Turn the engine off. Place a suitable container under the motorcycle. Remove the oil fill plug from the motor. Replace the O-ring if torn or damaged. Remove the left engine oil drain plug located in the crankcase. Wipe any accumulated debris from magnetic tip on drain plug and replace the aluminum washer. Remove the right oil drain plug located under the clutch cover. Wipe any accumulated debris from plug and replace the aluminum washer. After all oil has drained, tilt vehicle to right side to drain any remaining oil from the right side of engine. 1. If replacing the oil filter cartridge, perform the following: a. Remove the two screws to detach the oil filter cover. Remove filter cartridge from cover. b. Clean the cover and inside the oil filter recess in the crankcase. Remove any debris. NOTE: The rubber contact surface goes into the engine case cavity to seal the filter to the oil passages in the case. 2. Install new oil filter cartridge, if removed. a. Apply a light film of clean engine oil to the rubber contact surface on the new oil filter cartridge. b. Push new oil filter cartridge into cover until properly seated. c. Install oil filter cover (with filter) onto crankcase with two screws. Tighten screws to 11 Nm (97 in-lbs). 1. Install both drain plugs after the oil is thoroughly drained. a. Tighten left engine oil drain plug to 25 Nm (18 ft-lbs). b. Tighten right engine oil drain plug to 15 Nm (11 ft-lbs). 2. Fill through the oil fill hole. Install the plug. Make sure the plug is screwed in completely. When checking oil level is it meant to be done upright and warm (not leaning on kickstand). This was revised from 2008
