NXP’s 65 V LDMOS Design Reuse

http://www.nxp.com/65V http://www.richardsonrfpd.com/NXP65V Richardson RFPD’s Danny Molezion heads out to NXP's RF lab in Arizona to join Jim Davies to demonstrate the ease of use moving from a 1250 W device to the 1800 W MRFX1K80H using the same PCB. No retuning is needed for the 27 MHz board. Only five component changes are needed for the FM 87.5-108 MHz board. View at 4:00 minutes to see the following: C2: Replace 22pF with 33pF C12: Remove C13: Remove C14: Replace 15pF with 12pF L3: Replace with proper size detailed in MRFX1K80H datasheet
