🎥 Upcycling an old fluorescent light box into a new LED matrix LED Sign for a Hospital Radio Studio Welcome to Episode 3 of this 3-part mini-series, where we breathe new life into an old fluorescent light box and transform it into a bright, energy-efficient LED sign for a hospital radio studio! 🎶💡 Episode 1 here:    • Upcycling an Old Fluorescent Light Box int...   Episode 2 here:    • 🎥 Upcycling an old fluorescent light box i...   Please visit and support Care Waves Radio, hospital radio for Grimsby, Goole and Hull Hospitals: www.carewavesradio.co.uk Please subscribe to my channel here: http://www.youtube.com/MikesLEDShed?s... In this third video, I’ll be finishing off the wiring — running from the mains to the transformer, then on to the controller, and finally connecting up the LEDs. I’ll also take you through some important settings in the WLED software, including adjusting the maximum amps and, crucially, making sure the Red, Green, and Blue colour channels are set correctly. It’s a vital step to get your colours looking right and avoid any strange effects. If you're following along with your own build, this is one you won’t want to miss! This eco-friendly DIY project is perfect for anyone looking to recycle and modernise old signage using WLED. ⚠️If you’re not confident working with 240V mains electricity, please consult a qualified electrician. ⚠️ ♻️ Watch as we recycle, refurbish, and reimagine this old light box into a colourful, modern LED display for the studio. Let’s light it up! 🌈 🔧 What’s in this video: 00:00 – Introduction and wire layout overview 01:50 – Adding the 3-core LED cable (signal and power) 03:20 – A quick look at the inline fuse setup 07:00 – Powering everything on for the first time 07:45 – Connecting to an Android tablet to configure the controller 08:25 – Linking up with WLED software 09:34 – Setting LED preferences: number of LEDs, maximum amps, and colour order 14:15 – Fixing the LED strips and other components into place 14:56 – Chatting about those occasional random white flashes (usually a grounding issue) 21:12 – Wrapping up with an overview and a few extra tips 22:45 – Bonus clip: a look at the finished sign lit up in the studio Grab a brew and follow along — there’s plenty of handy info in this one! 💡 Total LEDs used: 10 rows x 30 = 300 LEDs 🎶 Music: Do Androids Dream of Electric Beats - By D-GR (C) Used with permission. Link:   / dave2000gray   🔌 Links to equipment used (non-sponsored): • LED Controller – https://www.amazon.co.uk/dp/B09TKL8TPL • 12v Transformer – https://www.amazon.co.uk/dp/B0CX8T92CW • WS2811 12v LED Strip – https://www.amazon.co.uk/dp/B01CNL6LBK • 240v Mains Fused IEC Socket – https://www.amazon.co.uk/dp/B09DRLYD2Z • ESP32 Kit – https://www.amazon.co.uk/dp/B0BYJ7S873 👉 Don’t forget to LIKE, SUBSCRIBE, and hit that 🔔 bell icon so you don't miss the next episodes! 💬 What would YOU put on your own custom LED sign? Let me know in the comments! #LEDSign #WLED #ESP32 #HospitalRadio #DIYLED #RecycledSign #RGBLighting #TechProject #LEDMatrix #MakersProject #WS2811 #ESP32Project #UKDIY #BritishMaker #ElectronicsBuild #StudioLighting
