TEK4 - EDM Repair + Vision

The machine is optionally supplied with a camera system that allows easy adaptive programming of Industrial Gas Turbine repaired components where new drilled holes need to be drilled relative to existing holes. ​ This system represents a breakthrough in flexibility, performance and ease of integration. This powerful vision system performs fast and accurately while its compact footprint easily fits into any TEK4 machine. ​ An integrated camera and lighting system is included to identify the location of the holes already drilled on the part – this is picked up by the EDM head. ​ Each time the camera system is picked up the position is calibrated by moving to a known feature on the datum bore. ​ Then the camera moves to identify the location of the reference holes that were selected by the operator, an automatic correction is applied to ensure that the new holes drilled are aligned to the existing holes.
