Airzone Blueface Thermostat Configuration

When the system is connected and the correct operation of the system LEDs has been confirmed, you can configure your Blueface thermostat. 1. The first parameter to set is language/country. Select the desired option and confirm. 2. The zone address corresponds to the number of the damper associated with the thermostat. It is important to remember that all ducted air conditioning units currently on the market provide greater air flow in the central zones of the plenum; therefore the largest zones in the installation should be associated with the plenum's central dampers. Use the arrows to select the zone address and confirm. 3. The next parameter to set is the zone's associated outputs. You can control several outputs in the same zone from a single thermostat. Select the required option and confirm. 4. Thermostat settings, where the master control of the interface is set. The master thermostat controls all the parameters for the entire installation, setting some of them as the operating mode for the whole system. The thermostat set as zone thermostat controls the parameters for its specific zone. 5. Depending on your installation and the elements associated, you may also be able to control the heating stages: Air, Radiant or Combined. 6. You can also change other settings by accessing the advanced settings menu or by activating only the thermostat's basic functions. Once your system is configured, if you want to return to default settings, you can reset the thermostat from the zone advanced settings menu. To do this, press and hold on Zone settings, enter the pattern as shown on the video and access Zone. The thermostat reset can be found on the second screen.
