Autodesk Inventor Tutorial for Beginners - Practice Part - Slip Nut Insert

Welcome to Autodesk inventor & solid edge tutorial channel - Slip Nut insert -This channel is dealing with everything about Autodesk inventor &Solid edge Beginners Tutorials – assembly And more,Click SHOW MORE Button. Slip joints can be designed to allow continuous relative motion of two components or it can allow an adjustment, by unclamping from one fixed position, and re-clamping to another. Examples of the latter are tripods, hiking poles, or similar telescoping device. The clamping mechanism is based on a cam, a set screw or similar locking mechanism. Slip joints can also be non-telescoping, such as the joints on some older wooden surveyor's levelling rods. These use a joint that keeps the sections offset from each other but able to be slid together for transport. Slip joints are sometimes found in tubular structures such as piping, but are generally avoided for this application due to requirements for sealing against leakage, instead using either a large loop that is allowed to flex or a semi-rigid bellows. Slip joints are used when the main problem is a large axial movement.[1] Pipe supports often are slip joints to allow for the thermal expansion or contraction of the pipe relative to the support. Slip joint connections are also commonly used in waste water plumbing, most commonly under kitchen sinks. Here, the slip joint provides a water-tight seal for non-pressurized drainage, with adjustability to aid installation. The slip joint includes a gasket that fits snugly on a pipe end, with a threaded nut behind the gasket, but with gasket position adjustable as needed. This pipe end fits loosely into another with a flange for the gasket to seal against, and threads for the nut to clamp the gasket to the flange. Learn more about solid edge tutorial on youtube:https://goo.gl/8aUwuz 1) Solid edge tutorials for beginners playlist:-    • Solid edge tutorial complete for beginner ...   2) Solid edge tutorial assembly    • Solid edge tutorial - 33 - Hinge design so...   3) Solid edge sheet metal tutorial playlist:-    • Solid edge tutorial - 51 - Sheet metal con...   4) Solid edge for beginner    • Solid edge tutorial complete for beginner ...   5) Solid edge basic tutorials    • Solid edge tutorial complete for beginner ...   6) Solid edge project    • Solid Edge tutorial - 44 - Propeller desig...   Thanks you watching tutorial videos...Don't forget subscribe this channel.
