Nixie tube with Arduino || Simplest design with Opto coupler only

This is my second experiment with Nixie tube, which on the way to making Nixie clock. Base on first experiment (   • Neon lamp (Nixie tube) player at 150VDC by...  ), i continue using Opto coupler chip TLP627 to control Nixie tube at 170VDC. Fortunately, everything works fine. So now i don't need to use nixie driver IC74141 which is difficult to purchase. ------------------------------------------ Part list to make project 1. Arduino UNO https://amzn.to/2P58O7s 2. Nixie tube 6 pcs https://amzn.to/3aHyJvX 3. Opto coupler chip TLP627 4. DC step-up module from 12VDC to 390VDC https://amzn.to/30kpdK9 5. Breadboard https://amzn.to/2uCrnsW ------------------------------------------------------------------- Code and circuit http://bit.ly/38KY1ri ----------------------------------------------------------------------------------------------- Other meaning video made by me, please help to support and SUBSCRIBE 1. Motor PID speed control http://bit.ly/2Slicag 2. Shadow light box http://bit.ly/2rtcrMN 3. DIY Portable infrared thermometer http://bit.ly/2M0NOhx 4. Temperature indicator http://bit.ly/2E5EhBl 5. How to program OLED screen http://bit.ly/2E7Q5mH 6. How to make ART CLOCK http://bit.ly/35SRV66
