How to Install The HP 9000 9040 9050 Maintenance Kit C9152A RG5-5750

Replacement Instructions for the HP 9000 9040 9050 M9059 Maintenance Kit C9152A HP 9000 Maintenance Kit Instructions The following parts are included in this maintenance kit: 1 Fusing Assembly RG5-5750 1 Transfer Roller Assembly RF5-3319 2 Paper Pickup Rollers RF5-3340 7 Feed/Separation Rollers RF5-3338 CAUTION: The fuser may be very hot. Turn off the printer and unplug the main power cord. Allow the printer to sit for 20 to 30 minutes before performing these maintenance procedures. Transfer Roller Removal and Replacement: 1. Open the front door of the printer and rotate large green lever downward 2. Pinch blue tab and pull transfer assembly out 3. Insert new transfer roller assembly into printer and slide in until it locks into place 4. Press the white button and rotate green lever back up until it locks 5. Close front cover NOTE: Do not touch the surface of the new transfer roller with bare hands. Skin oils on the roller can cause print defects. Tray 2 and Tray 3 Pickup/Feed/Separation Roller Removal and Replacement 1. Open tray 2 until it stops. Lift up on outer end and pull tray free 2. Repeat step 1 for tray 3 removal 3. Reaching in through the empty tray slots, pinch tabs on rollers and remove 4. Slide the new rollers onto the shafts until the tabs lock 5. Reinstall paper trays Optional Tray 4 Roller Removal and Replacement 1. Open the tray 4 and remove all paper 2. Locate blue release buttons on both sides of the tray 3. Slide buttons toward front of tray and pull tray out 4. Slide blue roller shield towards the back of Tray 4 5. Pinch tabs on the rollers and remove from shaft 6. Slide new roller on until tabs lock into place. NOTE: You do not need to slide the blue shield back over the roller 7. Replace the paper tray Fusing Assembly Removal and Replacement 1. Open left side access door 2. Remove duplexer if installed 3. Locate blue levers on each side of fuser and rotate them towards the middle 4. Lift up on handle and slide fuser out of printer 5. Align new fuser and slide firmly into printer until seated 6. Lock the blue tabs into position. NOTE: Do not force the levers. If they will not lock reseat the fuser and try again. 7. Reinstall duplexer if needed and close door Resetting Maintenance Count 1. Hold down the CHECK button while powering on the printer 2. Keep button depressed until all 3 lights are on 3. Use UP arrow or Down arrow key to scroll to “NEW MAINTENANCE KIT” 4. Press the CHECK button to select 5. Perform steps necessary to return printer to operation Repair Notes UPC : 725184846670 Alternate part numbers : HP C9152A, RG5-5750-170, RG5-5750-000, C9152-69005, C9152-67907, C9152-69007, C9152-67906, C9152-69004 Print Yield 350,000 pages Fits these printer models: HP LaserJet 9000 HP LaserJet 9000dn HP LaserJet 9000hnf HP LaserJet 9000hns HP LaserJet 9000LMFP HP LaserJet 9000MFP HP LaserJet 9000MFR HP LaserJet 9000n HP LaserJet 9040 HP LaserJet 9040dn HP LaserJet 9040MFP HP LaserJet 9040n HP LaserJet 9050 HP LaserJet 9050dn HP LaserJet 9050MFP HP LaserJet 9050n HP LaserJet M9040 HP LaserJet M9050MFP Metrofuser is a leading global innovator, manufacturer of printer parts, equipment, diagnostics, repair information and systems solutions for professional users performing critical tasks. Products and services include hp printer parts, printers and printer repair training. Parts include hp printer parts such as printer fusers, printer maintenance kits and other hp printer replacement parts. The company's, customers include office equipment dealerships, online retailers, repair centers and MPS service providers nationwide. Metrofuser has been named to Inc. Magazine’s fastest growing companies five consecutive years. Visit us at http://www.metrofuser.com
