Building a Model Layout in the Garage - Part 10 - Built my own analogue (PWM) Controller

So this is a carry over from the previous video, where I discuss the parts to build a PWM based analogue controller from parts sourced from eBay./ Components used DC Power Socket = https://www.ebay.co.uk/itm/12V-DC-POW... Switch = https://www.ebay.co.uk/itm/Miniature-... Motor Controller = https://www.ebay.co.uk/itm/DC-1-8V-3V... Plastic Box = https://www.ebay.co.uk/itm/ABS-BLACK-... Votatge and Amp Meter = https://www.ebay.co.uk/itm/4-Bits-DC2... Watch as I fumble my way through building it. 0:00 Intro 0:23 The Parts 1:40 Starting with the DC Socket 1:53 Testing the DC Socket 2:10 Making holes in the case 3:47 Start of the front face holes and cutting 5:30 Cutting the aperture for the Amp and Voltage Meter 6:!5 Bad job at cutting out the aperature 8:02 Powering up the meter 9:00 SOldering the switch 11:16 Combining the components 13:44 First test althougher 14:34 First test with a train and no Amps showing 16:00 Corrected wiring for it to work correctly I'm now on Patreon   / rowantown
