UWS-4 Aero Design: Part5b, Wing Airfoil Selection

In this part of the mini series of selecting the airfoil for the UWS-4 wing, we use the software program XFLR5 and our selection criteria from Part5 A to select our airfoil. We then determine the cruise angle of attack (incidence) for the main wing and capture the sectional characteristics (Cl, Cd, Cm) of our airfoil at cruse and stall with flaps deflected 45 degrees. Links: Youtube Channel:    / @designer103   Patreon:   / ultralight_airplane_workshop   Facebook:   / ultralightairplaneworkshop   Twitter:   / designer1032   Website: https://www.UltralightAirplaneWorksho... FAA AC 103-7: https://www.faa.gov/documentLibrary/m... Xflr5 software: Music: https://www.bensound.com Disclaimer: If you use any of the information that you see on this video on a project of your own, YOU become the engineer and responsible party for your project. It is possible that miscalculations were made in the production of this video. Since you are now the engineer for your project, you must verify the information that you use.
