2013 Mazak Hyper Quadrex 450MY CNC TURNING CENTER скачать в хорошем качестве

2013 Mazak Hyper Quadrex 450MY CNC TURNING CENTER

https://www.machineryvalues.com/inven... 2013 Mazak Hyper Quadrex 450MY CNC TURNING CENTER Mazatrol Matrix Control Maximum Swing 33.07" Machining Diameter 13.23" upper cutter Machining Diameter 11.14" lower cutter Bar Workpiece Capacity 7.24" Max. Machining Length 82.83" Dist. between spindle end and turret end face 6.994"-97.362" Max support weight Chuck workpiece 3968 lbs Max support weight Shaft workpiece 2923 lbs Max spindle speed 1500 rpm Spindle motor output (30min/cont rating) 50/40hp Maximum torque 1748.7 lbft Upper turret max # of tools 12 Upper turret mill spindle motor 10 hp Upper turret mill 4000 rpm Lower turret max # of tools 8 Tailstock CURRENTLY BEING REBUILT Tailstock travel 76.575" Coolant tank capacity 155.9 gallons Dimensions 236"L x 106.5"W x 96" H Machine weight 39000 lbs Includes Assortment of static holders plus (2) live holders 20" chuck 3 Jaw chuck SMW Autoblok (2) Mazak Superflow High Pressure Pumps 2000 PSI Steady rest mounted on lower turret Machine can be Inspected Under Power! Available 4/5/24
