Torsion Spring Design: Tips, Tricks, and Techniques in CREO PARAMETRIC- #5

Welcome to "BH-Cad" Compression spring design video link :    • DESIGN OF COMPRESSION SPRING IN CREO PARAM...   Today we going to see about how to design a simple Torsion spring using Creo Parametric 5.0 1) OPEN CREO PARAMETRIC 5.0 AND CLICK NEW, GIVE FILE NAME AND SELECT TEMPLATES AFTER THAT CLICK OK. 2) SELECT PLANE, CLICK SHITCH THEN SKETCH VIEW. 3) DRAW CENTERLINE AND CLICK LINE AND DRAW SPRING HEIGTH AS A LENGTH. 4) AFTER THAT CLICK SWEEP AND HELICAL SWEEP AND CLICK CREATE AND DRAW WIRE DIAMETER THEN GIVE PITH VALUE AS REQUIRED AND WINDING (LH OR RH). 5) CLCIK ONE END OF SPRING AND SKETCH THE LEG-1 AND SKETCH ANOTHER END DRAW LEG-2 AS IN 2D DRAWING AND CLICK OK. SPRING PITCH FORMULAS: 1. Closed Ends. p = (L–3d) ÷ Na. 2. Closed and Ground. p = (L–2d) ÷ Na. 3. Double Closed Ends. p = (L–5d) ÷ Na. 4. Open Ends. p = (L–d) ÷ Na. p = pitch. L = free length. d = wire diameter. Na = active coils. THANKS FOR WATCHING !!! SUBSCRIBE OUR CHANNEL FOR MORE VIDEOS
