Pattern and Scale Command || Transformation Features Toolbar || Catia V5 Tutorial Part Modeling - TOOLBAR - Transformation Features Toolbar COMMAND - Pattern and Scale Pattern - 1. Rectangular Pattern 2. Circular Pattern 3. User Pattern 1. Rectangular Pattern - You may need to duplicate the whole geometry of one or more features and to position this geometry on a part. Patterns let you do so, and by the way accelerate the creation process. These parameters are - 1. Instance and Length 2. Instance & Spacing 3. Spacing & length 4. Instance & Unequal Spacing ------------------------------------------------------------------------------------------------------------- 2. Circular Pattern - This tutorial shows you how to duplicate geometry of one or more features right away at the location of your choice using a circular pattern. These parameters are - 1. Instances & total angle 2 Instances & angular spacing 3. Angular spacing & total angle 4. Complete crown Failure of command - The Keep specifications option is not available if you are patterning a pattern. If you set Instances & total angle or Angular spacing & total angle parameters, note that you cannot define the total angle when using formulas. Reference Direction - Click the Reference element field and select the upper face to determine the rotation axis. This axis will be normal to the face. To define a direction, you can select an edge, a line, a planar face or a plane. After selecting an edge, a line or a planar face, if necessary, you can also select a point to define the rotation center. If you select a plane, selecting a point is mandatory. Crown Definition - 1. Circle & Crown thickness 2. Circle & circle spacing a 3. Circle spacing & Crown thickness ------------------------------------------------------------------------------------------------------------- 3. User Pattern - The User Pattern command lets you duplicate a feature, a list of features, or a body resulting from an association of bodies. as many times as you wish at the locations of your choice. Locating instances consists of specifying anchor points. These points are created in the Sketcher. This tutorial shows you how to duplicate a feature list including a pocket and a fillet at the points defined in the same sketch plane. ------------------------------------------------------------------------------------------------------------- Scale - Scaling geometry means resizing it to the dimension you specify, using points, planes or planar surfaces as scaling references. This tutorial shows how to scale a body in relation to a point. Affinity - You can change the parameters by using this command in each direction such as in X,Y and Z. ------------------------------------------------------------------------------------------------------------- To download assignments drawings link given below, https://www.design-mansion.com/search... For more details can follow my Website, https://www.design-mansion.com/ CATIA V5 Tutorial - CATIA V5 - Settings Video Link,    • CATIA V5 Tutorial || CATIA V5 SETTINGS for...   CATIA V5 Tutorial - CATIA V5 Sketcher Toolbar,    • CATIA V5 Tutorial || CATIA V5 Sketcher || ...   SKETCH-BASED FEATURES TOOLBAR || CATIA V5 Tutorial || Part Design,    • PAD COMMAND || CATIA V5 Tutorial || Part D...   DRESS-UP FEATURE TOOLBAR || CATIA V5 TUTORIAL|| PART DESIGN,    • Edge Fillet COMMAND || CATIA V5 Tutorial |...   Time-Saving Powerful Tips and Tricks - Catia V5 Tutorial,    • How to set space bar key for HIDE/SHOW || ...   Transformation Features Toolbar || CATIA V5 Tutorial,    • Translation, Rotation, Symmetry, Mirror ||...   ------------------------------------------------------------------------------------------------------------- Pattern, Scale, Transformation Features Toolbar, CATIA V5 Tutorial, COMMAND, how to use transformation features toolbar, how to use pattern, how to use scale, how to use circular pattern, how to use user pattern,how to use rectangular, how to use command ------------------------------------------------------------------------------------------------------------- To know more about cad software and Mechanical concepts, Please subscribe and press the bell icon to get the latest updates. Subscribe | Like | Share ------------------------------------------------------------------------------------------------------------- Thanks for Watching ... ------------------------------------------------------------------------------------------------------------- HashTags #TransformationFeaturesToolbar #Designmansion #Catiav5 #Pattern #Howto #command #3DDesign #Partmodeling #PartDesign #cad #caddesign #Toolbar #mechanical #mechanicalengineering #DesignEngineer
