PASS/START-PROF Overview Webinar: Your software for fast and easy pipe stress analysis

START-PROF® makes complex things simple Timeline: 00:00 Welcome session 12:56 Adding Supports 14:29 Setting Allowable Loads for the Anchor 16:05 Spring Hanger Selection 18:44 Load Cases. Operating modes with different T, P 22:09 Seismic, Wind, Snow, Ice Load Generation 34:00 Flange Leackage Check, Valve 37:39 Expansion Joints 42:15 Creep Stresses in Hot and Cold State with Self Cold-Springing Effect 46:19 Adding Restraint Movement 48:29 Nozzle Flexibility Calculation Using FEA (Finite Element Analysis) 51:27 Inserting the Non-Standard Tee Object with FEA Flexibilities 57:56 Creating the Buried Pipeline (Underground) 01:01:13 Inserting the U-shaped Expansion Loop on Buried Pipeline 01:02:53 Ring Bending 01:03:44 Creating FRP/GRP/GRE Piping with ISO 14692 01:05:31 Creating Thermoplastic Piping from PE 100 Material 01:06:33 Importing CAESAR II File 01:08:46 Generating Stress Analysis Report in Microsoft WORD
