Prob. 3.3-2. A bimetallic bar is made by bonding together two homogeneous rectangular bars, each having a width b and length L. The moduli of elasticity of the bars are E1 and E2, respectively. An axial force P is applied to the ends of the bimetallic bar at (y=yP, z=0) such that the bar undergoes axial deformation. Let L=1.5m, b=50 mm,t1=25 mm, t2=15 mm, E1=70 GPa, E2=210 GPa, and P=48 kN. (a) Determine the normal stress in each material, that is, determine σ1 and σ2. (b) Determine the value of yP. (c) Determine the total elongation, e, of the bar. I would be feeling sincerely thankful if y'all can subscribe, comment, and like each video to support this channel because by doing this, the YouTube algorithm moves these videos up the search list and allows more people to receive help from me. Thank you all. My email: TheengineeringWei@gmail.com Book: Mechanics and Materials 4th Edition Author: Roy R. Craig | Eric M. Taleff ISBN-13: 978-1-119-60375-7 Email me if you want: 1. Specific problems that you would like me to make a video on 2. Further support on a specific question 3. Personal Tutor (online)
