How to build ATS panels for generators.

How can an ATS panel for a generator be built in a short time? https://ats-panels.com/how-to-build-a... First, reduce the number of components. Second, install the most compact and powerful ATS controller in the world. You save 10 relays, 30 meters of cable and many points of connections. Third, follow our instructions. Put a robust metallic panel suitable for electrical installation in a horizontal position. The Be242 needs a round hole: easy to make. Forget square holes and download our footprint. Use a file to finish the hole and protect it from rusting. Install the controller on the door with 4 screws. Fix the cable to the panel. Select carefully the components by following our wiring diagram. Make all mechanical work. Put the interface board on the rail. Install the battery charger, the contactors, the current transformers, the circuit breakers, and the terminal blocks. Finally, install the plastic conduits. First, start wiring the auxiliary circuits for the generator and mains. Wire the contactors inputs and outputs using a cable of suitable size. Connect the measurement circuits for the generator and mains. Connect the coils of the contactors. You will connect the engine on-site. Your panel is ready for testing. You can make ATS panels for small or large generators. Follow our web tutorial, which includes all the information about testing and the final checklist before delivering the panel to your customer.
