3D High Speed Waterline Toolpath Enhancements in Mastercam 2022

Machining with a Spiral Pattern and New Contour Directions: The Cut Method drop-down on the Cut Parameters page has been replaced with the Closed contour direction and Open contour direction drop-downs. These new drop-downs allow you to create more efficient cutting motion and include reduced retracts on open contours. • Closed contour direction: Sets the cutting direction for closed contours, creating continuous motion without the need for a retract or reversal of direction. • Open contour direction: Sets the cutting direction for open contours. Waterline also includes two new Closed contour direction options, Climb Spiral and Conventional Spiral. These new cut styles provide cleaner finishes, less machining motion, and fewer retracts. Spiral also helps to avoid creating marks on your part due to stepdown motion. • Climb spiral: Cuts in one direction in a spiral pattern, with the tool rotating in the opposite direction of the tool motion. • Conventional spiral: Cuts in one direction in a spiral pattern, with the tool rotating in the same direction as the tool motion. Machining Flat Areas: You can now determine how a Waterline toolpath handles flat areas in a part. Use the new Critical Depths group on the Cut Parameters page to further customize this handling. Use the Type drop-down option to determine the types of flat areas to be machined, such as Flats only, which allows you to machine only flat areas. You can also manually select the flat areas using the Manual option, or you can use Extend to expand out these flat areas. Optimizing the Cut Order: When machining bosses and features that are close to each other, Mastercam now optimizes the cut order for Waterline toolpaths. Learn more about What's New in #Mastercam2022 here: https://whatsnew.mastercam.com/. Or get in touch with your local Reseller here: https://mastercam.com/find-a-reseller/ Looking for more online learning tools? Get started here: https://mastercam.com/support/trainin... Join the Mastercam community on social: Instagram:   / mastercamcadcam   Facebook:   / mastercam   Education Facebook:   / mastercameducation   Twitter:   / mastercam   LinkedIn:   / cnc-software   Get the latest Mastercam news delivered to your inbox. Sign up for our newsletters here: https://mastercam.com/news/digital-ne...
