3" (76mm) ERW Tube mill, Pipe making machine, Pipe production line, Tube mill Line

Whatsapp: 86-15176910262 Email: Linda@aismachinery.com Skype:285119853@qq.com Web: www.aismachinery.com 1. Summary The mill is intended for manufacturing of round pipe of 19mm-Φ76mm with thickness of 0.8mm–4.0mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.Finished product will be of round, square or rectangular pipe. 2. The technical flow of the production line {Steel Tape}→→ Double-head un-coiler →→Strip-head Cutter and welder→→Spiral accumulator→→Forming section（Flattening unit +Main driving unit +Forming unit +Guide unit +High frequency induction welding unit +squeeze roller）+ De-burr frame →→Cooling unit →→Sizing unit and straightener →→Flying saw under computer-control →→ Run-out table 3.Basic conditions: a.Round Pipe: Φ19-Φ76mm b.Pipe Thickness: 0.8– 4.0mm c.Square Pipe: 20X20mm –60X60mm d.Rectangle Pipe: 15X25mm –40X80mm e.Pipe Thickness: 0.8–3.0mm f.Pipe Length: 5.0~12.0m Steel Tape Specification Material: Low Carbon steel & Galvanized steel (δb≤500Mpa, δs≤235Mpa) Steel Tape: Inner diameter: Φ508-Φ610mm Outer diameter: Φmax=1500mm Strip steel width: 40mm-240mm Strip steel thickness: 0.8mm-4.0mm The maximum weight: 4.0tons
