Join us for an in-depth exploration of the integration of Building Information Modeling (BIM) with Reality Capture technology, focusing on the X-Grids K1 Scanner and its application in various fields such as architecture, construction, and surveying. The session includes an introduction to SLAM technology, best practices for scanning, processing scan data using LixelStudio, and integrating the data with Autodesk Recap and Revit. We will demonstrate the workflow by using data from a recent scan of the Frank Lloyd Wright House at Ebsworth Park in St. Louis County, Missouri. 00:00:00 - Welcome 00:02:08 - Introduction to XGRIDS K1 Scanner 00:09:11 - Uses and Best Practices 00:13:54 - Processing, Cleanup, and Export 00:16:21 - Frank Lyold Wright Home Case Study 00:25:32 - Autodesk ReCap Pro and Revit Workflow 00:27:39 - Transitiopn to Autodesk Workflow 00:29:23 - Importing LAS into Autodesk ReCap Pro 00:31:30 - Cleaning up a point cloud in ReCap Pro 00:34:32 - Importing into Revit without a Mesh Model 00:36:51 - Creating a Mesh Model in ReCap Pro 00:41:32 - Working with a Mesh Model in ReCap Pro 00:47:04 - Exporting a Mesh Model for Revit 00:48:12 - Importing into Autodesk Revit 00:53:08 - Q&A 00:54:01 - Link to Blog 00:54:20 - Q&A: What's the quality of the wall brought into the Revit file? 00:56:28 - Q&A: What's the vertical accuracy? 00:56:57 - Q&A: What's the near field capability of the XGRIDS K1? 00:58:00 - Q&A: Is the placeholder snappable? 00:58:54 - Q&A: What is meant by GPS time? 01:00:51 - Q&A: What is the RTK antenna rated for accuracy? #BIM, #RealityCapture #SLAM #XGRIDS #K1Scanner #Autodesk #RecapPro #Revit #3DModeling #pointcloud #meshmodel #LixelStudio #bestpractices #RTKantenna #seiler #seilerdesignsolutions #architecture #franklloydwright
