Simcenter 3D - How to Create a CAD Model from Finite Elements

Are you an old school analyst who likes to work with nodes and elements but sometimes needs to communicate finite element changes back to Design. We have you covered with NX Polygon Modeling and Reverse Engineering. This demonstration will show how create a CAD model from nodes and elements. This can be accomplished by exporting the FEM as a JT file and then opening the newly created JT file. The new part will show faceted data which can then be converted to a convergent body. The Replace Mesh with Face and Rapid Surfacing commands can be used to modify faces and edges on the body. ‪@SiemensSoftware‬ ‪@SiemensKnowledgeHub‬
