Rover OX CNC - PT1 of 2 - Upgrade Frame

Many of you commented that my build seemed a little flimsy due to using 80x20 and 60x20 V rails, I tended to agree so with the help from SNB Solutions ( https://snbinc.ca/ ) I have upgraded my CNC to a much more robust frame and plates. Here is how I did it... The solution is based on the Rover OX design and this adds substantial increase in rigidity and also height and other build options It consists of changing out the frame to one based on 80x40 C Section V Rails, upgraded Y plates adding a complete set of additional wheels doubling the contact area with the rails and an upgraded X plates supporting an additional set of wheels for the Z axis. Oh and the Feet, I upgraded from small 5 hole triangle plates to massive and very strong Rover Feet that in addition to keeping the frame very firmly supported, adds the ability to use Ball or Acme Screws with Nema 24 or 34 Steppers... Awsome I call my new build the BullDog, it maintains the same dimentions regarding the cutting surface but with about 6 more inches in vertical (Z Axis) height. This first video covers the upgrade to the Frame includng the Rover Feet, Rover Frame and Rover X and Y plates All parts used in the upgrade are available from SNB Solutions under their Rover OX Tab found here :- https://snbinc.ca/store/index.php?cPa...
