Jig Pins and Captive Locating Screws, quick-acting, all-in-one tooling!

Captive Locating Screws and Captive Jig Pins from Carr Lane Mfg. Co. are quick-acting, all-in-one assemblies to keep all tooling right at hand. Both assemblies have a precision-ground body that is positively retained in a locking bushing, with a spring clip that snaps into the body’s radial groove. In addition, spring pressure holds the Captive Locating Screw in place, an advantage especially if the fixture is turned upside down while handling. Captive Locating Screws can be used for locating and clamping in one action or for clamping only by selecting the appropriate screw length. Captive Locating Screws are available with a socket-head, hand-knob, or swivel-washer hand-knob, each in a wide selection of diameters and lengths. Captive Jig Pins provide quick-acting location without clamping, and also offer positive retention in a locking bushing. These pins are available in several locating diameters and have an integral shoulder to keep the handle raised. -- Since 1952, Carr Lane Manufacturing Company has been committed to being the world’s preferred source of tooling components by continuously improving products, processes, and services to exceed our customers’ expectations. Carr Lane Jig Pins: https://www.carrlane.com/product/alig... Carr Lane Captive Locating Screws: https://www.carrlane.com/product/alig... More information about Carr Lane: https://www.carrlane.com/ Follow Carr Lane on Social Media:   / carrlanemfgco     / carr-lane-manufacturing-co-
