NCS5500 for the Confused

This video has been created and published in Jan 2020, it aimed at clarifying the different options available in the very rich Cisco NCS5500 portfolio. Since this publication, many new products have been introduced and the recommendations present in this video must be taken with a grain of salt. It must be considered for what it is: an archive. Please contact your Cisco representative for the latest details. This video aims at answering the following questions: how to read the product ID? which one does what? what are the different ASICs? which routers are oversubscribbed? how many prefixes can I store in them? how many 400G, 200G, 100G, 40G, 10G ports can I populate in each option? where can I use break-out cables? 4x25G or 4x10G? Or port adapter? how deep they will be in my rack? which ones support MACsec encryption? which ones support timing features? For direct access to the different sections of this very long video: ---------------------------------------------------------------------------------------------------- 0:00 • Intro 2:46 • Fixed systems naming logic 3:40 • NCS5501(-SE) overview 4:02 • NCS5502(-SE) overview 4:00 • NCS55A1-36H(-SE)-S overview 4:38 • NCS55A1-24H overview 5:00 • NCS55A2-MOD-* overview 5:45 • NCS55A1-24Q6H-S overview 6:06 • NCS55A1-48Q6H overview 6:22 • Modular Chassis commons (RP, SC, fabric, fan tray) overview 8:10 • Line cards overview 11:01 • Platforms sorted based on Forward ASICs (Qumran-MX, Jericho, Jericho+ with or without large LPM, with or without eTCAM, Jericho2) 15:57 • Platforms sorted based on interface type support (400G, 200G, 100G, 40G, 25G, 10G, breakout, QSA, ...) 28:08 • Platforms sorted based on the routing/FIB scale 31:13 • Platforms supporting MACsec L2 encryption 32:16 • Platforms supporting timing (syncE, PTP) 33:05 • Platforms sorted based on the chassis depth ----------------------------------------------------------------------------------------------------
