Two Transistor Radio Frequency Oscillator Circuit

Here is a extremely simple RF Radio Frequency Circuit that only uses two transistor... only 2 transistor.. no diodes... no resistive dividers.. That is it!! It is a high power RF oscillator circuit that can operate in the HF range. I will show the construction and testing of this amazing device.. as well as the circuit diagram! Here are the links for some of the parts and test equipment I used to build this simple high power RF device! Network analyzer: https://amzn.to/4bW1THt Spectrum Analyzer https://amzn.to/3Rc5ebT Alligator Clips https://amzn.to/3Rc5Q1b
