Draw SFD and BMD for Simply Supported Beam Carries Two Uniformly Distributed Loads & One Point Load

In this video we are going to learn about how to draw Shear Force Diagram [SFD] and Bending Moment Diagram [BMD] for Simply Supported beam of length 6 meter which carries one point load of 5 kilo Newton and two uniformly distributed loads of 4 kilo Newton per meter and 2 kilo Newton per meter acting on the beam as shown in the video This problem we are going to solve it, in 3 simple steps. 1. Calculate the values of support Reaction forces. 2. Calculation of Shear force 3. Calculation of Bending Moment Timecodes 0:07 - Problems on Shear force and Bending Moment Diagram [SFD and BMD] for Simply Supported Beam 1:11 - Convert uniformly distributed loads into point loads 1:50 - Calculations of Support Reaction forces for Simply Supported Beam 6:31 - Shear force Calculations for Simply Supported Beam 15:45 - Bending Moment Calculations for Simply Supported Beam 17:20 - Sagging Effect and Hogging Effect for Simply Supported Beam 21:06 - Calculations of Maximum Bending Moment #shear_force_and_bending_moment_diagram #simply_supported_beam #strength_of_materials You can also watch separate videos for Shear Force and Bending Moment Problems on 4 types of beams - Cantilever Beam -    • Cantilever Beam: Shear Force and Bending M...   Simply Supported Beam -    • Simply Supported Beam: Shear Force and Ben...   Overhanging Beam -    • Overhanging Beam: Shear Force and Bending ...   Simply Supported Beam with Uniformly Distributed Load -    • Uniformly Distributed Load (UDL): Shear Fo...   You can also watch Playlist on Shear Force and Bending Moment Solved Problem Shear force and Bending Moment Diagram Solved Problems -    • Shear force and Bending Moment Diagram Sol...   Faculty - Shubham Rukman Kola Email ID - shubhamkolaofficial@gmail.com From - Maharashtra ( India ) YouTube Channel ( Shubham Kola ) -    / @ifinfotech   Disclaimer - video is for educational purpose only. Copyright Disclaimer Under Section 107 of the Copyright Act 1976, allowance is made for "fair use" for purposes such as criticism, comment, news reporting, teaching, scholarship, and research. Fair use is a use permitted by copyright statute that might otherwise be infringing. Non-profit, educational or personal use tips the balance in favour of fair use. The content in this video is collected from books, media, internet space etc. This is strictly for educational and information purposes and is not intended to be advice or recommendation of any kind whatsoever. The faculty is not a subject expert. The faculty is sharing his knowledge in the form of videos. The faculty giving small basics information on mechanical engineering topics. We endeavour to keep the information up to date and correct, we make no representations or warranties of any kind, express or implied, about the completeness, accuracy, reliability, suitability or availability with respect to the video or the information, related graphics contained in the video for any purpose. any reliance you place on such information is therefore strictly at your own risk. In no event will we be liable for any loss or damage without limitation, indirect or consequential loss or damage, or any loss or damage whatsoever arising from loss of data or profits arise out of, or in connection with, the use of this video.
