How to Wire Two Dimmer Switches in One Electrical Box

Here we'll show you how to wire up two Lutron Diva LED+ light dimmer switches in one electrical box to control two separate light circuits. Then we'll show you how to adjust the light level when the dimmer switch is at the lowest setting. In this project we installed a new electrical box in the wall, but these instructions will work if the box is already there and has 3 cables coming into it - one for each light circuit and one for power. A voltage tester can help you figure out which is which, if you're not sure. This is what I used (as an Amazon Associate I earn from qualifying purchases): Dimmer Switches: https://amzn.to/3Dtgf5p Voltage Tester: https://amzn.to/43y4JQH Wire Strippers: https://amzn.to/4jFpCOz Wago Connectors: https://amzn.to/4615IcL Screwless Wall Plate: https://amzn.to/4l6CcZD Timestamps: 00:00 - Intro 00:42 - Finding the Power Cable 00:58 - Wiring the Switches 04:42 - Dimmer Settings 05:41 - Wall Plate
