Designing of 2-Bit Magnitude Comparator (Part-2)| Tech Gurukul By Dinesh Arya

Designing of 2-Bit Magnitude Comparator (Part-2)| Tech Gurukul By Dinesh Arya Description Digital Comparator A magnitude digital comparator is a combinational circuit that compares two digital or binary numbers (consider A and B) and determines their relative magnitudes in order to find out whether one number is equal, less than or greater than the other digital number. Three binary variables are used to indicate the outcome of the comparison . It compares the two numbers of n-bit length and generates their relation between themselves. Link for playlist of K-Map    • K-MAP (Karnaugh MAP) by Dinesh Arya   Link for playlist of Combinational circuits    • Combinational Circuits
