Self Terminating Keystone Jack - How to install ethernet wire to the jack, Step by step instruction

https://nettechnow.com/collections/et... The 1409 Self Terminating Cat 6 Keystone Jack White from Network Tech Components are ready to use ethernet jacks. This pack includes 5x, 10x or 25x self terminating cat6 keystone jacks in white color. These standard jacks are white in color, have a 90 degree angle for the termination section and can support ethernet wire in 22 to 26 gauge. The jacks are made with PC UL94V-0 material. The contact pins inside the jack are gold plated which prevents rust and helps ensure consistent data transmission. The jacks have a special wire groove in their center and a sturdy dust cover. This prevents small material from getting into the jack and also helps reduce the strain on the cable when moving. The jacks are specially made with cutting ribs inside of the ethernet conductor sections that terminate the wire without the need for a punching tool. To use these cutting edges place the ethernet conductors in their designated grooves and use the sturdy dust cap to firmly press down on the jack. After this grab the end of one of the ethernet conductors and move it in a circle until it breaks away from the jack. Repeat this for each conductor to complete the jack. With this said, a punch tool can also be used to finish these jacks. Specifications: Type: Cat 6 keystone jack Amount: 5x, 10x or 25x keystone jacks Color: White Angel: 90 degree Material: PC UL94V-0 Operating Temperature: -20°C or -4°F to 60°C or 140°F Contacts: Gold plated Pinouts: T568A & T568B #ntcfl #networktechcomponents #cat6jack #keystonejack #toolessinstall
