Brushless Motors Encoder Setup and Calibration [Torque + Speed Verified]

NEW UPDATED VIDEO HERE:    • Brushless Motors Encoder Setup and Calibra...   This video demonstrates how to set up and calibrate your incremental Encoder with SOLO to control Torque, Speed, and Position of Brushless motors of any kind ( BLDC, PMSM, and EC coreless). The video starts by showing the correct connection for Encoder wires and then it shows how the 3 phase motor wires' should be connected and verified by checking the Torque and Speed behavior. To learn more you can visit: https://www.solomotorcontrollers.com/... Order one: https://www.solomotorcontrollers.com/... The link to Motion Terminal: https://www.solomotorcontrollers.com/... 0:00 intro 0:56 Incremental Encoder Wires Connection 2:14 Encoder Connection Verification in Motion Terminal 4:39 Motor wires combination check and Initial setups 7:04 Encoder Calibration for a candidate of wirings 8:55 The behaviour of a correct combination 9:40 Torque loop test on a working combination 10:55 Speed loop test on a working combination #BLDC #servoDrive #PMSM #EC_Coreless #Torque #Speed
