How to Monitor MySQL/MariaDB through Prometheus & Grafana ?

Please follow the below steps to install mysqld_exporter. curl -s https://api.github.com/repos/promethe... | grep browser_download_url | grep linux-amd64 | cut -d '"' -f 4 | wget -qi - tar xvf mysqld_exporter*.tar.gz sudo mv mysqld_exporter-*.linux-amd64/mysqld_exporter /usr/local/bin/ sudo chmod +x /usr/local/bin/mysqld_exporter CREATE USER mysqld_exporter IDENTIFIED BY 'PASSWD'; GRANT PROCESS, REPLICATION CLIENT, SELECT ON . TO 'mysqld_exporter'; FLUSH PRIVILEGES; EXIT Configure DB Credential sudo vi /etc/.mysqld_exporter.cnf [client] user=mysqld_exporter password=PASSWD host=192.168.56.109 Change ownership sudo chown root:prometheus /etc/.mysqld_exporter.cnf Create Systemd File sudo vi /etc/systemd/system/mysql_exporter.service [Unit] Description=Prometheus MySQL Exporter After=network.target User=prometheus Group=prometheus [Service] Type=simple Restart=always ExecStart=/usr/local/bin/mysqld_exporter \ --config.my-cnf /etc/.mysqld_exporter.cnf \ --collect.global_status \ --collect.info_schema.innodb_metrics \ --collect.auto_increment.columns \ --collect.info_schema.processlist \ --collect.binlog_size \ --collect.info_schema.tablestats \ --collect.global_variables \ --collect.info_schema.query_response_time \ --collect.info_schema.userstats \ --collect.info_schema.tables \ --collect.perf_schema.tablelocks \ --collect.perf_schema.file_events \ --collect.perf_schema.eventswaits \ --collect.perf_schema.indexiowaits \ --collect.perf_schema.tableiowaits \ --collect.slave_status \ --web.listen-address=0.0.0.0:9104 [Install] WantedBy=multi-user.target sudo systemctl daemon-reload sudo systemctl enable mysql_exporter sudo systemctl start mysql_exporter Import Mysql Grafana Dashboard https://grafana.com/grafana/dashboard...
